mechanical design engineering
Design Engineering
- It is the branch of mechanical engineering that deals with the design, analysis, and optimization of an individual part or the combination of parts such that they form a mechanical system.
- Often the subject which the Design Engineer learns at an entry level consists
- Advance Mathematics.
- Material Science & Mechanincal Behaviour of Materials.
- Advance Stress Analysis.
- Analysis & Synthesis of Mechanism.
- Advance Mechanical Vibration.
- Finite Element Method.
- Research Methodology.
Computer Aided Drawing
- It is the method by which we create technical 2D drawings, 3D models of an 'individual part', or 'the component', or 'assembly of part or component that makes a particular mechanism or machine' that the manufacturer can understand.
- In many cases of CAD software now, can now conduct the analysis & optimization of the part can be conducted. However, the accuracy and ease of conducting analysis can vary from software to software.
- Some of the CAD software used in industry are mentioned below: -
- CATIA
- SOLIDWORKS
- CREO
- AUTODESK FUSION 360
- NX, etc
Computer Aided Engineering
- It is the method by which we can conduct the analysis and optimization of a particular part or assembly of parts, taking into consideration the material properties and under the applied loads & boundary conditions, which represent the real-life conditions the part or assembly is subjected to, using the principles of 'Finite Element Method'
- ANSYS
- HYPERWORKS
- ANSA, etc.
